Touring Recumbent Quad-Model 420

Select your model
  • -$-4,299.00
  • Regular price $4,299.00
    /
    Click here to be notified by email when Touring Recumbent Quad-Model 420 becomes available.
    Type: Recumbent Quads

    Description

    420 is built primarily for people who prefer more excellent stability, better ride view, excellent ground clearance, and additional cargo capacity, which makes it the perfect utility vehicle for traveling.

    Key Features

    Medium seat height: The medium seat height help you get on and off the trike easily and provides a clear view of traffic.

    Ergo mesh seat: The Ergo-mesh seat is designed to provide optimum back support. The cover features breathable fabrics to maximize airflow while cushioning in the base and side bolsters enhances comfort.

    Superior transmission system: The two-stage transmission system minimizes the component size and provides efficient working. Meanwhile, it reduces the tension to maximize chain life.

    Power divider: The power diver is designed to drive a pair of wheels while allowing them to rotate at different speeds when turning a corner. Moreover, the divider can ensure one wheel to keep turning when slip occurs on the other wheel.

    Good ground clearance: Medium seat height offers a good ground clearance, ideal for roads and trail use.

    Air suspension: The rear air suspension can be optimized by a simple adjustment, which delivers a more comfortable and controlled ride.

    Large rear rack: The open designed stainless steel rear rack gives an ideal storage solution for large and heavy loads.

    Measurement



    Overall width: 90 cm/35.43 in

    Overall height: 91 cm/35.83 in

    Overall length: 180-200 cm/ 70.87-78.74 in

    Track width: 85 cm/33.46 in

    Wheelbase: 110 cm/ 43.31 in

    Ground clearance: 17 cm/6.69 in

    Bottom seat height: 37 cm/ 14.57 in

    Seat width: 37 cm/ 14.57 in

    Seat depth: 25 cm/ 9.84 in

    Seat angle: 40°

    Turning circle: 4.0 m/ 157.48 in

    Wheel size: 50.8 cm/ 20 in

    Max. load: 125kg/ 275.58 lb

    Rider height: 165 - 200 cm/ 5'4'' - 6'56''

    Components

    Frame: Aluminum 6061 T6Seat: Ergo-fiberglass seat

    Tires: Kenda 20x1.35"

    Front brakes: Avid BB7 mountain mechanical disc brake

    Rear brakes: Avid BB7 mountain mechanical disc brake

    Brake levers: Avid FR-5

    Shifter: Shimano Alivio SL-M4000 3x9-speed

    Front derailleur: Shimano Sora FD-3503-B

    Rear derailleur: Shimano Alivio RD-M4000 9-speed

    Crankset: Shimano Sora FC-3503 50-39-30T

    Cassette: Shimano CS-HG400-9 9-speed 11-32T

    Chain: Shimano CN-HG73 9-speed

    Suspension: DNM AOY-36RC Air Shock


    Optional (420E/M)

    Motor: 36v 250w mid-motor

    Battery: 36v 11.6Ah lithium battery with Panasonic cells

    Display: LCD

    Crankset: 48T with torque sensor pedal assist
