Available with a variety of gear options. The fat tires provide excellent float and traction over the soft ground and bumpy trail. You can switch between the fat tires and standard tires in the use of different terrains. Custom-built front and rear mudguard protect the quad from all circumstances.
Wide range gears
Available with a variety of gear options, F326E can be geared for the most challenging terrain.
A low seat position and the recline angle as little as 30 degree minimizes frontal area and reduces aerodynamic drag.
Fat tire and normal tire can be converted simply and freely. It not only gives you a lot of fun on different terrains, also help you save much cost.
You can have two models (326 & F326) if you buy one F326 and extra road wheel set.
Overall width: 38.58 in
Overall height: 41.34 in
Overall length: 77.80 in - 85.67 in
Track width: 34.25 in
Wheelbase: 53.15 in
Ground clearance: 5.31 in
Bottom seat height: 13.39 in
Seat width: 14.57 in
Seat Depth: 9.84 in
Seat angle: 30°
Turning circle: 170.08 in
Weight: 50.71 lb
Wheel size: 24 in
Rider height: 64.96 in - 78.74 in
Max. load: 275.58lb
Frame: Aluminum 6061 T6
Seat: Ergo-fiberglass seat
Tires: 20x4.0"/ 26x4.0" rear
Front brakes: Avid BB7 mountain mechanical disc brake,
Rear brake: Avid BB7 mountain mechanical disc brake,
Brake levers: Avid FR-5
Shifter: Shimano Alivio SL-M4000 3x9-speed
Front derailleur: Shimano Alivio FD-M4000-DS
Rear derailleur: Shimano Alivio RD-M4000 9-speed
Crankset: Shimano Alivio FC-M4050 40-30-22T
Cassette: Shimano CS-HG400-9 9-speed 11-32T
Chain: Shimano CN-HG73 9-speed
Motor: Bafang Mid Motor BBS02 48v 500w
Battery: 48v 14.5Ah lithium battery with Panasonic cells
Display: Bafang Colorful LCD
Crankset: Bafang 42T with pedal assist
