Entry-level Folding Suspension Recumbent Trike
-
Features
- Foldable High carbon steel frame.
- Adjustable mesh seat with 3 positions.
- The rear suspension provides a more comfortable, smoother, better-controlled ride.
- Shimano 3×8 wide gears range.
- Free useful accessories, including headrest, rear rack, mirrors, fenders, and flag.
-
Description
You want an attractive recumbent tricycle without getting into the technical details of the trike world? Then the M-009 is a good choice: clear lines, raised seating position, no compromises when it comes to equipment. A great trike for small budgets.
-
Applications
Commuting, traveling, exercising, rehabilitation
Product Specs
|
Technical Data
|
|
Components
|
|
|
Overall width
|
78.3 cm
|
Frame
|
High carbon steel
|
|
Overall height
|
85 cm
|
Seat
|
Ergo-mesh seat
|
|
Overall length
|
198-216 cm
|
Tires
|
CST 20x1.5" front / 26x1.5" rear
|
|
Track width
|
76.2 cm
|
Front brakes
|
Avid BB5 mountain mechanical disc brake
|
|
Wheel base
|
126 cm
|
Rear brake
|
Promax V-brake
|
|
Ground clearance
|
14.6 cm
|
Brake levers
|
Shimano ST-EF51
|
|
Bottom seat height
|
30.3 cm
|
Front derailleur
|
Shimano Tourney FD-TX51
|
|
Seat width
|
37 cm
|
Rear derailleur
|
Shimano Tourney FD-TX51
|
|
Seat depth
|
39.1 cm
|
Crankset
|
Shimano Tourney FC-TX71 48-38-28T
|
|
Seat angle
|
42-49°
|
Cassette
|
Shimano Altus CS-HG31 8-speed 11-34T
|
|
Turning circle
|
5.0 m
|
Chain
|
8-speed
|
|
Weight
|
24.5 kg
|
Option 1 (Model: M-009E)
|
|
|
Wheel size
|
20 front / 26rear
|
Motor
|
36v 250w rear hub motor
|
|
Max. load
|
125 kg
|
Battery
|
36v 12Ah lithium battery
|
|
Rider height
|
160-195 cm
|
Display
|
LCD display
|
|
|
|
Option 2 (Model: M-009E/M)
|
|
|
|
|
Motor
|
36v 250w mid drive motor
|
|
|
|
Battery
|
36v 12Ah lithium battery
|
|
|
|
Display
|
LCD display
|
|
|
|
Crankset
|
48T with torque sensor pedal assist
|
